°C
%RH
Modbus

Showcase humidity and temperature sensors HYGRASGARD® VFTF-Modbus

SKU 1201-6126-1000-100 EAN 4 251325 616582 Product group: WG02
Not available

This product is no longer manufactured. Discover the new successor model with improved performance and additional features

VFTF-Modbus-SD

VFTF-Modbus-SD

1201-612H-1000-100

$617.42
$617.42
$617.42

Auf die Merkliste

Add to wishlist

Añadir a la lista de favoritos

Aggiungi alla lista dei preferiti

Добавить в список желаний

Ajouter à la liste de souhaits

Product description

  • 0...100 % RH-35...+80 °C / -31...-176 °F
  • ± 2 %
  • Temperature [°C], relative humidity [% RH], dew point [°C], absolute humidity [g / m3], mixing ratio [g / kg], enthalpy [kJ / kg]
  • Modbus RTU
  • IP65
Calibratable showcase humidity and temperature sensor HYGRASGARD® VFTF - Modbus with Modbus connection, terminal box housing made of impact-resistant plastic, housing cover with quick-release screws, optionally with/without display.

The universal display case sensor is used to determine various humidity measurement technology parameters.
The relative humidity and the temperature of the ambient air are measured.
Various parameters are calculated internally from these measured variables. The following parameters can be queried via Modbus: relative humidity [% RH], absolute
humidity [g/m³], mixing ratio [g/kg], dew point temperature [°C], enthalpy [kJ/kg]
(disregarding atmospheric air pressure) and ambient temperature [°C].

The measuring transducer is designed for the exact recording of temperature and humidity.
A digital, long-term stable sensor is used as the measuring element for humidity and temperature. Fine adjustment by the user is possible.

The display case sensor is used in non-aggressive, dust-free environments and is especially suitable for installation in ceilings, walls, display cases or showcases in museums, galleries, cinemas, auditoriums or laboratories. The measuring element is located in a stainless steel probe and is hardly noticeable due to its very low height (approx. 2.5 mm).
