Differential pressure transmitter

Our PREMASREG® and PREMASGARD® differential pressure transmitters are used for the precise measurement of relative, absolute and especially differential pressure.
The measured pressure values are converted into a standard signal of 0-10 V or 4...20 mA.
Piezoresistive measuring elements ensure high accuracy and long-term stability.
Typical applications include the monitoring of ventilation and air conditioning ducts, filter monitoring or differential pressure measurement in technical systems.

Guide and interesting facts about differential pressure transmitters
199 products
  • Differenzdruckmessumformer mit geschlossenem Gehäuse in Draufsicht
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7115-U VA

    2004-6191-1200-011

    594,55 €

  • Differenzdruckmessumformer mit geschlossenem Gehäuse in Draufsicht
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7115-I VA

    2004-6191-2200-011

    594,55 €

  • Differenzdruckmessumformer in Seitenansicht mit geschlossenem Gehäuse
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7111-U VAQ

    2004-6191-1100-001

    634,97 €

  • Differenzdruckmessumformer mit geschlossenem Gehäuse in Seitenansicht
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7111-I VAQ

    2004-6191-2100-001

    634,97 €

  • Differenzdruckmessumformer in Draufsicht mit geschlossenem Gehäuse
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7115-I VAQ

    2004-6191-2100-011

    634,97 €

  • Feuchte- und Temperaturmessumformer mit geschlossenem Gehäuse und Display
    Pa / bar / inWC °C +1
    Si Imp Modbus

    Duct humidity and temperature sensor with integrated Pressure- and differential pressure transmitter

    PREMASGARD 8148-Modbus LCD

    1301-8144-4910-20V

    640,78 €

  • Differenzdruckmessumformer mit geschlossenem Gehäuse und Montagehalterung
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7115-U VAQ

    2004-6191-1100-011

    651,48 €

  • Differenzdruckmessumformer mit geschlossenem Gehäuse
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7110-U VA

    2004-6191-1200-021

    662,02 €

  • Differenzdruckmessumformer mit geschlossenem Gehäuse in Draufsicht
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7110-I VA

    2004-6191-2200-021

    662,02 €

  • Differenzdruckmessumformer mit geschlossenem Gehäuse in Draufsicht
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7110-U VAQ

    2004-6191-1100-021

    705,83 €

  • Differenzdruckmessumformer mit geschlossenem Gehäuse in Seitenansicht
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7110-I VAQ

    2004-6191-2100-021

    705,83 €

  • Differenzdruckmessumformer mit geschlossenem Gehäuse in Draufsicht
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7112-U VA VE

    2004-6191-1200-031

    763,03 €

  • Differenzdruckmessumformer mit geschlossenem Gehäuse in Draufsicht
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7112-I VA VE

    2004-6191-3200-001

    763,03 €

  • Differenzdruckmessumformer mit Display in Frontalansicht
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7111-U VA LCD

    2004-6192-1200-001

    797,41 €

  • Differenzdruckmessumformer in Frontalansicht mit Display
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7111-I VA LCD

    2004-6192-2200-001

    797,41 €

  • Differenzdruckmessumformer mit Display in Frontalansicht
    Pa / bar / inWC

    Pressure- and differential pressure transmitters

    PREMASGARD 7115-U VA LCD

    2004-6192-1200-011

    797,41 €

Pressure transmitters for air and differential pressure measurement - for ventilation, clean rooms and building automation

Author: S. Becker | Status: 06.03.2026

Differential pressure transmitters - often referred to as differential pressure sensors or Δp sensors - measure the pressure difference between two points and convert this into an electrical output signal.

In a nutshell

A pressure transducer for air measures positive, negative or differential pressure between two points - typically in the range from 25Pa to several kPa. In practice, this means

  • Reliable filter monitoring
  • Stable volume flow calculation
  • Safe pressure zones in clean rooms
  • Reproducible control variables for BMS and DDC

It is not only the measuring range that is important here - but resolution, temperature compensation and zero-point stability.

Contents

Measuring principle & accuracy in the low pressure range Selection guide from practice - Which pressure transmitter is the right one? Installation, pressure acceptance and influence on measurement quality Typical applications in HVAC, clean room and industry

Why differential pressure is crucial in ventilation technology

In HVAC technology, we often work in the low pressure range - 50, 100 or 300 Pa.
That doesn't sound like much, but it is technically demanding.

Typical applications:

  • Differential pressure across filter (degree of contamination)
  • Δp measurement on fans
  • Volume flow rate determination via orifice plates or Pitot tubes
  • Pressure cascades in clean rooms or laboratories
  • Monitoring of positive or negative pressure zones

The quality of the differential pressure sensor is crucial, especially for small pressure differences:

  • Control stability
  • Energy efficiency
  • Maintenance intervals
  • Operational safety

Measuring principle & accuracy in the low pressure range

Our differential pressure transmitters for air work with temperature-compensated piezoresistive sensor elements.

Why is this important?
In the range below 300 Pa, even a small temperature drift can have a noticeable effect on the measured value.

Without compensation:

  • Incorrect filter messages
  • Unstable volume flow controls
  • Unnecessary maintenance work

That's why we pay particular attention during development:

  • Low temperature drift
  • Stable zero point position
  • High resolution with small Δp

Practical selection guide - Which differential pressure transducer is the right one?

We see the same challenges in projects time and time again. So here are our most important selection criteria:

  1. Select the correct measuring range
    A measuring range that is too large reduces the resolution.

    Example:
    If a maximum of 250 Pa occurs, a 0-1000 Pa device is technically possible - but not optimal in terms of measurement technology.

    Rule of thumb:
    The operating pressure should be in the upper third of the selected measuring range.

  2. Unidirectional or bidirectional?
    0...+300 Pa → Filter monitoring
    -300...+300 Pa → Pressure zones / clean room

  3. Output signal
    0-10 V → Standard in BMS
    4-20 mA → interference-free with longer cables

  4. Signal filter
    In the case of strongly fluctuating pressure ratios (e.g. fans with frequency converters), an adjustable signal filter is useful in order to obtain a stable output signal.

Calculate volume flow measurement with differential pressure

Many applications use Δp for indirect volume flow measurement - for example in ventilation systems, VAV systems or air ducts.

The basis is:

V = k - √Δp

A square-rooted output that already forms the square root internally can be useful for this. This reduces the computational effort in the DDC and improves the control quality.
This is a real advantage, especially in VAV systems.

Zero point stability & long-term behavior

The zero point is particularly critical for differential pressure sensors in the low pressure range. Even slight mechanical or thermal changes can lead to offset shifts.

That is why our devices have:

  • Automatic or manual zero point calibration
  • Temperature-compensated measuring cells
  • Sturdy housing construction

This ensures reproducible measurement results - even in continuous operation.

Typical applications

  • Filter monitoring in HVAC systems
  • Differential pressure measurement in ventilation ducts
  • Clean room and laboratory monitoring
  • Fan control
  • Volume flow measurement
  • Overpressure or underpressure monitoring in technical rooms
  • Differential pressure measurement in extraction and process air systems

Air vs. liquids

This category includes differential pressure transmitters for air and non-aggressive gases, as typically used in ventilation systems, clean rooms or HVAC systems.

For applications with water, cooling circuits or hydraulic systems, we recommend our pressure transmitters for liquids in the bar range. A suitable selection for liquids is available in a separate category.

To category Pressure transmitters for liquids

Our differential pressure transmitters and differential pressure sensors for air

Here you will find devices with:

  • Multi-range switching
  • 0-10 V / 4-20 mA
  • optional display
  • IP65/IP67 housing
  • easy-to-install hose connections
  • high long-term stability
Select the right pressure transmitter now

We also manufacture individually

Do you have special requirements? As a manufacturer with our own production facilities in Germany, we are also able to produce products outside of the standard range at any time.
