Products – Page 46 – S+S Regeltechnik

°C
Immersion temperature sensor

THERMASGARD® TF54 Pt1000 200mm

1101-7050-5041-000
−35...+180 °C
PT1000
Insertion length: 200 mm
2-wire connection
Output variant: Compression terminal
IP54
$92.61
Stainless steel thermowell

Thermowells TH-MS/VA TH-VA NPT 8in

7100-0012-0040-231
8 inch
NPT 1/2"
Stainless steel V4A (1.4571)
max. Pressure: 40 bar
max. Medium temperature: +600 °C
Suitable for: TF 54/ TM 54 (Form B)
$92.65
°C
Immersion temperature sensor

THERMASGARD® TF54 Ni1000 200mm

1101-7050-9041-000
...+180 °C
NI1000
Mounting depth: 200mm
2-wire connection
Output version: compression screw
IP54
$92.69
°C
Temperature measurement transducer

THERMASGARD® TM43-I 50mm

1101-7112-0019-900
Mounting insertion length: 50mm

– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

4...20 mA

IP54
$92.83
°C
Temperature transducer

THERMASGARD® TM43-U 50mm

1101-7111-0019-900
Installation length: 50 mm

– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

0 - 10 V

IP54
$92.83
°C
Immersion temperature sensor

THERMASGARD® TF54 NTC1.8K 200mm

1101-7051-2041-000
−35...+150 °C
NTC 1.8K
Immersion length: 200 mm
Two-wire connection
Output version: Compression screw
IP54
$92.84
°C
Immersion temperature sensor

THERMASGARD® TF54 NTC10K 200mm

1101-7051-5041-000
−35...+150 °C
NTC 10K
Immersion depth: 200 mm
Two-wire connection
Output version: Compression screw
IP54
$92.84
°C
Immersion temperature sensor

THERMASGARD® TF54 NTC20K 200mm

1101-7051-6041-000
–35...+150 °C
NTC 20K
Insertion length: 200mm
2-wire connection
Output version: compression screw
IP54
$92.84
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt100 250mm

1101-7050-1053-000
...35 to +180 °C
PT100
Insertion length: 250 mm
4-wire connection
Output variant: compression fitting (pressure screw)
IP54
$93.01
°C
Immersion temperature sensor

THERMASGARD® TF54 NiTK 200mm

1101-7051-0041-000
–35...+180 °C
NI1000TK5000
Installation length: 200 mm
2-wire connection
Output variant: compression fitting
IP54
$93.02
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt1000 250mm

1101-7050-5051-000
— 35...+180 °C
PT1000
Insertion length: 250 mm
2-wire connection
Output version: compression screw
IP54
$93.09
°C
Room temperature sensor with control element

THERMASGARD® RTF NTC1.8K P L T

1101-40A1-2663-347
passive
−30...+70 °C
2-wire connection
Potentiometer, LED displays, presence pushbuttons
$93.18
°C
Immersion temperature sensor

THERMASGARD® TF54 LM235Z 400mm

1101-7052-1081-000
–35...+125 °C
LM235Z
Immersion length: 400mm
2-wire connection
Output variant: compression fitting
IP54
$93.26
°C
Immersion temperature sensor

THERMASGARD® TF54 Ni1000 250mm

1101-7050-9051-000
–35...+180 °C
NI1000
Mounting length: 250mm
Two-wire connection
Output variant: Compression fitting
IP54
$93.26
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt100 300mm

1101-7050-1063-000
–35...+180 °C
PT100
Insertion length: 300 mm
4-wire connection
Output version: compression screw
IP54
$93.35
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt1000 300mm

1101-7050-5061-000
–35...+180 °C
PT1000
Immersion depth: 300 mm
2-wire connection
Output variant: compression screw
IP54
$93.35

We also manufacture individually

Do you have special requirements? As a manufacturer with our own production facilities in Germany, we are also able to produce products outside of the standard range at any time.
