Products – Page 76 – S+S Regeltechnik

°C
Screw-in temperature controller

THERMASREG® ETR-090090 U VA/150

1102-2010-2205-130
Dual temperature controller (internal setting)
1. Temperature range: 0 ... +90 °C
2. Temperature range:
Tmin ± 5 K; Tmax ± 3 K
Output: switching / changeover
Switching power (contact rating):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
for 24 V at least 150 mA
Switching differential: 3K
Water, oil, air and exhaust gases
Material: stainless steel
Mounting depth: 150 mm
IP65
$188.01
°C
Sleeve sensor with temperature transmitter (cable temperature transmitter)

THERMASGARD® HFTM-I Q

2001-2111-2100-001
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typically ± 0.2 K at +25 °C
4...20 mA
M12 plug connector
IP65
$188.04
°C
Sleeve sensor with temperature transmitter (cable temperature transmitter)

THERMASGARD® HFTM-U Q

2001-2111-1100-001
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typically ± 0.2 K at +25 °C
0 - 10 V
M12 plug connector
IP65
$188.04
°C
Room temperature transmitter

THERMASGARD® RTM-U PU

1101-41A1-0004-346
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

typically ± 0.2 K at +25 °C

0 - 10 V

Potentiometer (0 - 10 V)

IP30
$188.51
°C
Room temperature transmitter

THERMASGARD® RTM-A P

1101-41AE-0004-346
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typically ± 0.2 K at +25 °C
0-10V / 4..20mA
Potentiometer (0 - 10 V)
IP30
$188.51
°C
Temperature measurement transmitter

THERMASGARD® TM43-I 400mm LCD

1101-7112-2089-900
Insertion depth: 400mm

– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

4...20 mA

IP54
$188.57
°C
Temperature transmitters

THERMASGARD® TM43-U 400mm LCD

1101-7111-2089-900
Insertion length: 400 mm

– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

0 - 10 V

IP54
$188.57
°C
Screw-in sensor - immersion temperature sensor with neck tube (single offset)

THERMASGARD® ETF7 Pt100 250mm

1101-2080-1053-000
–35...+150 °C

Temperature

Pt100

Very fast response time

4-wire connection

IP65
$189.30
°C
Screw-in sensor - immersion temperature sensor with neck tube (single offset)

THERMASGARD® ETF7 Pt1000 250mm

1101-2080-5051-000
−35...+150 °C

Temperature

Pt1000

Very fast response time

2-wire connection

IP65
$190.19
Light
Ceiling-mounted brightness sensor

PHOTASGARD® DHKF U

1601-6121-1000-000
Light sensor

0...500 lux / 0... 1 kLux / 2 kLux / 5 kLux / 20 kLux / 60 kLux

0-10V

IP30, IP65, IP67
$190.34
Light
Ceiling-mounted brightness sensor

PHOTASGARD® DHKF I

1601-6122-1000-000
Light sensor

0...500 lux / 0... 1 kLux / 2 kLux / 5 kLux / 20 kLux / 60 kLux

4..20 mA

IP30, IP65, IP67
$190.34
°C
Room temperature sensor or transducer

THERMASGARD® FSTM-U P

1101-9121-0004-282
0...+50 °C

typically ± 0,8 K at +25 °C

Temperature [°C]

0-10V

Equipment: Potentiometer
$191.82
Sale

CO2 + VOC
Room air quality sensor / Room CO2 and air quality sensor

AERASGARD® RLQ-CO2-W

1501-61B1-7301-200
0...2000 ppm / 0...5000 ppm
0...100 % air quality - VOC sensitivities (low/medium/high)
Air quality (VOC), carbon dioxide (CO2)
0-10V / 4..20mA + changeover contact
IP 30
$496.95

$192.00
°C
Screw-in sensor - immersion temperature sensor with neck tube (single offset)

THERMASGARD® ETF7 NiTK 100mm

1101-2081-0021-000
–35...+150 °C

Temperature

Ni1000TK5000

Very fast response time

2-wire connection

IP65
$192.56
Pa / bar / inWC
Pressure- Differential pressure and volume flow transducers

PREMASGARD 1121-SD-I

1301-1182-0010-000
±1000Pa
Accuracy: ± 10 Pa
4..20mA
IP54
Digitized output signal adjustable
$192.59
