°CTHERMASREG® ETR-060R85 VA/150
1102-2010-7205-230
- Temperature controller (external setting) + safety temperature limiter
- 1. temperature range: 0...+60 °C
2nd temperature range: +65...+85 °C - Tmin ± 5 K; Tmax ± 3 K
- Output: Switching / changeover contact
- Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA - Switching differential: +0 / -15...20K
- Water, oil, air and exhaust gases
- Material: stainless steel
- Installation length: 150 mm
- IP65
$177.22
$210.85
-
°CTHERMASREG® ETR-090R110 VA/150
1102-2010-7205-330
- Temperature controller (external setting) + safety temperature limiter
- 1. temperature range: 0...+90 °C
2nd temperature range: +90 ... +110 °C - Tmin ± 5 K; Tmax ± 3 K
- Output: Switching / changeover contact
- Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA - Switching differential: +0 / -15...20K
- Water, oil, air and exhaust gases
- Material: stainless steel
- Installation length: 150 mm
- IP65
$177.22
$210.85
-
°CTHERMASREG® ETR-090090 U VA/150
1102-2010-2205-130
- Double temperature monitor (internal setting)
- 1. temperature range: 0 ... +90 °C
2. temperature range: - Tmin ± 5 K; Tmax ± 3 K
- Output: Switching / changeover contact
- Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA - Switching differential: 3K
- Water, oil, air and exhaust gases
- Material: Stainless steel
- Installation length: 150 mm
- IP65
$177.22
$210.85
We also manufacture individually
Do you have special requirements?As a manufacturer with our own production facilities in Germany, we are always in a position to produce products outside the standard range.
