Modbus measuring devices

Modbus is a proven, manufacturer -independent communication protocol for reliable and quick data transmission in building automation. Developed for simple and cost -effective networking, it enables communication between controls, sensors and control technology systems - regardless of the manufacturer.

S+S Regeltechnik offers a wide range of sensors with Modbus interface for all relevant application areas in building automation.

°C + % RH
WIRELESS room controller (controller)

Rymaskon® RYM 1442C-TH-OTFS-WM-FM-B

RYM1-4421-W220-000
Rymaskon® 1000 C Controller - 230V
Temperature [°C] [°F],
relative humidity [% RH]
Control: Temperature, Fan
Output: W-Modbus (RTU) / W-BACnet (MS/TP), switching output
Input: 1x NTC10K, 1x digital
Power supply: 230 V AC
Flush-mounted installation
IP30
$382.14
°C + % RH
WIRELESS room controller (controller)

Rymaskon® RYM 1451C-TH-OTFS-WM-FM-W

RYM1-4511-W220-000
Rymaskon® 1000 C Controller - 230V
Temperature [°C] [°F], relative humidity [% RH]
Control: Temperature, Fan
Output: W-Modbus (RTU) / W-BACnet (MS/TP), 0-10V, switching
Input: 1x NTC10K, 1x digital
Power supply: 230 V AC
Flush-mounting
IP30
$382.14
°C + % RH
WIRELESS room controller (controller)

Rymaskon® RYM 1452C-TH-OTFS-WM-FM-B

RYM1-4521-W220-000
Rymaskon® 1000 C Controller - 230V
Temperature [°C] [°F],
relative humidity [% RH]
Control: temperature, fan
Output: W-Modbus (RTU) / W-BACnet (MS/TP), 0-10V, switching
Input: 1x NTC10K, 1x digital
Power supply: 230 V AC
Flush-mounting
IP30
$382.14
°C + % RH
WIRELESS room controller (controller)

Rymaskon® RYM 1461C-TH-OTFS-WM-FM-W

RYM1-4611-W210-000
Rymaskon® 1000 C Controller - 24V
Temperature [°C] [°F],
relative humidity [% RH]
Control: Temperature, Fan
Output: W-Modbus (RTU) / W-BACnet (MS/TP), 0-10V, switching
Input: 1x NTC10K, 1x digital
Power supply: 24 V AC / DC
Flush-mount (in-wall)
IP30
$382.14
Pa / bar / inWC
Dual pressure sensor as pressure transmitter and differential pressure transmitter

PREMASGARD 7249-Modbus LCD

1301-7224-4930-200
2 measuring channels (1./2.): ±500/±17000 Pa
± 13 Pa / ± 105 Pa
Modbus
IP65 / IP67
$390.28
Pa / bar / inWC
Dual pressure sensor as pressure transmitter and differential pressure transmitter

PREMASGARD 7247-Modbus LCD

1301-7224-4950-200
2 measuring channels (1/2): ±1000/±1000 Pa
<\/li>
± 105 Pa
<\/li>
Modbus
<\/li>
IP65 / IP67
<\/li><\/ul>
$390.28
°C + % RH
Room operating humidity and temperature sensor

HYGRASGARD® RFTF-Modbus P T D5 5L

1201-42B6-6121-841
0...100 % RH
0...+50 °C

Temperature [°C], relative humidity [% RH],
dew point [°C], absolute humidity [g / m³],

Potentiometer, rotary switch, presence pushbutton, LED indicators

Switchable metric / imperial

Modbus

IP30
$392.60
MWTM Modbus SD, 6.0 m

1101-328H-0260-000

$392.73
m/s
Flow monitor

RHEASGARD® KLGF-Modbus 120mm

1701-4216-0102-000
0.1...20 m/s
Flow velocity
Modbus RTU
IP 65, sensor technology IP 20
Mounting depth: 120 mm
$394.25
°C + % RH
Room operating humidity and temperature sensor

HYGRASGARD® RFTF-Modbus P T 5L LCD

1201-42B6-7051-005
0...100 % RH
0...+50 °C

Temperature [°C], relative humidity [% RH],
dew point [°C], absolute humidity [g / m³],
mixing ratio [g / kg], enthalpy [kJ / kg]

Potentiometer, presence pushbutton, LED displays

Switchable metric / imperial

Modbus

IP30
$399.68
°C + % RH
Room humidity and temperature sensors or transmitters

HYGRASGARD® FSFTM-Modbus P

1201-9226-1400-282
0...100 % RH
0...+50 °C

Temperature, relative humidity, absolute humidity,
dew point, mixing ratio, enthalpy
as well as setpoint potentiometers
(no setpoint adjustment possible for Busch-Jaeger)

Modbus

IP20
$403.47
°C + m/s + m³/h
Flow monitor

RHEASGARD® KLGFVT-Modbus

1701-4216-0401-000
0.1...20 m/s
0...200,000 m³/h
Temperature, flow velocity, volume flow rate
Modbus RTU
IP 65, sensor technology IP 20
Installation dimensions: 220 mm
$408.71
m/s + m³/h
Airflow monitors

RHEASGARD® PLGFV-Modbus

1701-6216-0301-000
0.1...20 m/s
Flow velocity, volumetric flow rate
Modbus RTU
Power supply: 24 V AC / DC
Mounting depth: 155 mm
IP65
$408.71
CO2
Room air quality sensors

AERASGARD® RCO2-Modbus LCD

1501-61B0-6021-200
0...5000 ppm
Carbon dioxide (CO2)
Modbus RTU
IP 30
$414.09
°C + % RH + VOC
Room operating unit (interface)

Rymaskon® RYM 1301-THV-OTS-M-SM-W

RYM1-3011-M711-000
Rymaskon® 1000 Interface
Temperature [°C] [°F],
relative humidity [% RH],
air quality (VOC)
Control: temperature
Output: Modbus RTU / BACnet (MS/TP)
Input: 1x NTC10K, 1x digital
Surface mounting
IP30
$414.12
°C + % RH + VOC
Room operating unit (interface)

Rymaskon® RYM 1302-THV-OTS-M-SM-B

RYM1-3021-M711-000
Rymaskon® 1000 Interface
Temperature [°C] [°F],
relative humidity [% RH],
air quality (VOC)
Control: Temperature
Output: Modbus RTU / BACnet (MS/TP)
Input: 1x NTC10K, 1x digital
Surface mounting
IP30
$414.12

We also manufacture individually

Do you have special requirements? As a manufacturer with our own production facilities in Germany, we are also able to produce products outside of the standard range at any time.
