Temperature

Our quality products in the area of temperature measurement technology Thermasgard® and Thermasreg® meet the highest demands after precision, innovation and durability. S+S control technology also inspires with sophisticated thermostats, active temperature sensors and passive temperature sensors and many other solutions around the temperature measurement technology.

Your advantage: our holistic understanding of temperature measurement for a wide variety of applications and a high degree of technical experience as a manufacturer of robust and high -quality temperature sensors. If you have any questions about our product range, we are always happy to be there for you.

°C
Mean value temperature sensor / rod sensor

THERMASGARD® MWTF Pt1000 3m

1101-3050-5231-000
-30...+80 °C
Temperature [°C]
PT1000
Cable length: 3.0 m
Two-wire connection
IP65
$186.35
°C
Temperature measurement transducers

THERMASGARD® TM43-I 350mm LCD

1101-7112-2079-900
Installation length: 350mm

– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

4...20 mA

IP54
$186.45
°C
Temperature measuring transducer

THERMASGARD® TM43-U 350mm LCD

1101-7111-2079-900
Insertion length: 350mm

– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

0 - 10 V

IP54
$186.45
°C
Screw-in sensor - immersion temperature sensor with neck tube (single offset)

THERMASGARD® ETF7 Pt1000 150mm

1101-2080-5031-000
−35...+150 °C

Temperature

Pt1000

Very fast response time

2-wire connection

IP65
$186.45
°C
Screw-in temperature controller

THERMASREG® ETR-060R85 VA/150

1102-2010-7205-230
Temperature controller (outdoor setting) + safety temperature limiter
1. Temperature range: 0...+60 °C
2. Temperature range: +65...+85 °C
Tmin ± 5 K; Tmax ± 3 K
Output: switching / changeover contact
Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA
Switching differential: +0 / -15...20K
Water, oil, air and exhaust gases
Material: stainless steel
Mounting depth: 150 mm
IP65
$188.01
°C
Screw-in temperature controller

THERMASREG® ETR-090R110 VA/150

1102-2010-7205-330
Temperature controller (external setting) + safety temperature limiter
1. Temperature range: 0...+90 °C
2. Temperature range: +90 ... +110 °C
Tmin ± 5 K; Tmax ± 3 K
Output: switching / changeover
Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1,0
24...250 V AC +10 %, 1,5 A, cos ϕ = 0,6
for 24 V at least 150 mA
Switching differential: +0 / -15...20K
Water, oil, air and exhaust gases
Material: stainless steel
Installation depths: 150 mm
IP65
$188.01
°C
Screw-in temperature controller

THERMASREG® ETR-090090 U VA/150

1102-2010-2205-130
Dual temperature controller (internal setting)
1. Temperature range: 0 ... +90 °C
2. Temperature range:
Tmin ± 5 K; Tmax ± 3 K
Output: switching / changeover
Switching power (contact rating):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
for 24 V at least 150 mA
Switching differential: 3K
Water, oil, air and exhaust gases
Material: stainless steel
Mounting depth: 150 mm
IP65
$188.01
°C
Sleeve sensor with temperature transmitter (cable temperature transmitter)

THERMASGARD® HFTM-I Q

2001-2111-2100-001
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typically ± 0.2 K at +25 °C
4...20 mA
M12 plug connector
IP65
$188.04
°C
Sleeve sensor with temperature transmitter (cable temperature transmitter)

THERMASGARD® HFTM-U Q

2001-2111-1100-001
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typically ± 0.2 K at +25 °C
0 - 10 V
M12 plug connector
IP65
$188.04
°C
Room temperature transmitter

THERMASGARD® RTM-U PU

1101-41A1-0004-346
– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

typically ± 0.2 K at +25 °C

0 - 10 V

Potentiometer (0 - 10 V)

IP30
$188.51
°C
Temperature measurement transmitter

THERMASGARD® TM43-I 400mm LCD

1101-7112-2089-900
Insertion depth: 400mm

– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

4...20 mA

IP54
$188.57
°C
Temperature transmitters

THERMASGARD® TM43-U 400mm LCD

1101-7111-2089-900
Insertion length: 400 mm

– 20...+ 150 °C / – 50... + 50 °C / – 20... + 80 °C / – 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

0 - 10 V

IP54
$188.57
°C
Screw-in sensor - immersion temperature sensor with neck tube (single offset)

THERMASGARD® ETF7 Pt100 250mm

1101-2080-1053-000
–35...+150 °C

Temperature

Pt100

Very fast response time

4-wire connection

IP65
$189.30
°C
Screw-in sensor - immersion temperature sensor with neck tube (single offset)

THERMASGARD® ETF7 Pt1000 250mm

1101-2080-5051-000
−35...+150 °C

Temperature

Pt1000

Very fast response time

2-wire connection

IP65
$190.19
°C
Room temperature sensor or transducer

THERMASGARD® FSTM-U P

1101-9121-0004-282
0...+50 °C

typically ± 0,8 K at +25 °C

Temperature [°C]

0-10V

Equipment: Potentiometer
$191.82

We also manufacture individually

Do you have special requirements? As a manufacturer with our own production facilities in Germany, we are also able to produce products outside of the standard range at any time.
