Product description
- 0...50 / 0...100 / 0...300 / 0...500 μg/m³
- Temperature, relative humidity, particulate matter (PM)
- active (0 -10 V / 4...20 mA), changeover contact
- IP 30
The entire room climate can be effectively monitored and controlled with just one device. This enables energy-saving, needs-based room ventilation and thus a reduction in operating costs and an increase in well-being. It is used in offices, hotels, conference rooms, apartments, stores, etc. A long-term stable, digital humidity and temperature sensor guarantees exact measurement results. The CO2 content of the air is determined using an optical NDIR sensor (non-dispersive infrared technology). An optical particle sensor precisely detects fine dust (PM) in the size category 0.3 to 10 micrometers. The sensor is calibrated at the factory; fine adjustment by a specialist is possible depending on the environment.
Technical data
| Measurement | Temperature, relative humidity, fine dust (PM) |
| Power supply | 24 V AC/DC (± 10%) |
| Output | 0-10V / 4..20mA, changeover / relay (24 V) |
| Display | Yes |
| Measured quantity in addition to °C + %RH | +PM |
| Measuring range | 0...50 / 0...100 / 0...300 / 0...500 µg/m³ |
| Features | Changeover |
| Output | 0 -10 V or 4...20 mA (selectable via DIP switch, the selected variant applies uniformly to all outputs), load < 800 Ω |
