°CTHERMASREG® FST-8D-HR
1102-1024-1102-000
- Temperature limiter (with manual reset)
- -10...+15 °C/ +14...+59 °F,
Factory setting w = +5 °C (+41 °F) - Switching capacity:
10 (2) A, AC 250 V;
due to the gold-plated contacts also
switching of signal voltages < 24 V - Switching differential: 2 ± 1 K (3.6 ± 1.8 °F)
- Capillary tube length: 0.6 m
- Sensor response length: approx. 40 cm
- Sensor: copper
- Permissible medium: Air
- IP65
$118.34
$140.76
-
°CTHERMASREG® ETR-0120 VA/100
1102-2010-1100-590
- Temperature controller (external setting)
- 0 ... +120 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA - Switching differential: 5K
- Installation length: 100 mm
- Stainless steel
- IP65
$119.18
$141.79
-
°CTHERMASREG® ETR-060 VA/100
1102-2010-1100-390
- Temperature controller (external setting)
- 0 ... +60 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA - Switching differential: 3K
- Installation length: 100 mm
- Stainless steel
- IP65
$119.18
$141.79
-
°CTHERMASREG® ETR-090 VA/100
1102-2010-1100-490
- Temperature controller (external setting)
- 0 ... +90 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA - Switching differential: 3K
- Installation length: 100 mm
- Stainless steel
- IP65
$119.18
$141.79
-
°CTHERMASREG® ETR-1 VA/100
1102-2010-1100-190
- Temperature controller (external setting)
- -35 ... +35 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA - Switching differential: 3K
- Installation length: 100 mm
- Stainless steel
- IP65
$119.18
$141.79
-
°CTHERMASREG® ETR-50140 VA/100
1102-2010-1100-690
- Temperature controller (external setting)
- +50 ... +140 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA - Switching differential: 5K
- Installation length: 100 mm
- Stainless steel
- IP65
$119.18
$141.79
-
°CTHERMASREG® ETR-060 U VA/100
1102-2010-2100-390
- Temperature monitor (internal setting)
- 0 ... +60 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA - Switching differential: 3K
- Installation length: 100 mm
- Stainless steel
- IP65
$119.18
$141.79
-
°CTHERMASREG® ETR-090 U VA/100
1102-2010-2100-490
- Temperature monitor (internal setting)
- 0 ... +90 °C
- Tmin ± 5 K; Tmax ± 3 K
- Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA - Switching differential: 3K
- Installation length: 100 mm
- Stainless steel
- IP65
$119.18
$141.79
We also manufacture individually
Do you have special requirements?As a manufacturer with our own production facilities in Germany, we are always in a position to produce products outside the standard range.
