°C
Contact temperature controller

THERMASREG® ALTR-3 U

1102-1030-2100-300
Temperature monitors (indoor setpoint)

0...+60 °C

Tmin ± 5 K; Tmax ± 5 K

Switching capacity (contact load):
24 … 250 V AC + 10 %, 16 A, cos ϕ = 1.0
24 … 250 V AC + 10 %, 1.5 A, cos ϕ = 0.6
at 24 V AC min. 150 mA

Switching differential: 5K (± 1K)

Endless voltage in the metal tension clamp
(is included in the scope of delivery)

IP65
$142.10
°C
Contact temperature controller

THERMASREG® ALTR-5 U

1102-1030-2100-400
Temperature controller (indoor setting)

0 ... 90 °C

Tmin ± 5 K; Tmax ± 5 K

Switching capacity (contact load):
24 … 250 V AC + 10 %, 16 A, cos ϕ = 1,0
24 … 250 V AC + 10 %, 1,5 A, cos ϕ = 0,6
at 24 V AC min. 150 mA

Switching differential: 5K (± 1K)

Endless voltage in the metal tensioning clamp
(included in the scope of delivery)

IP65
$142.10
°C
Contact temperature controller

THERMASREG® ALTR-7 U

1102-1030-2100-500
Temperature controller (indoor setting)

0...120 °C

Tmin ± 5 K; Tmax ± 5 K

Switching power (contact load):
24 … 250 V AC + 10 %, 16 A, cos ϕ = 1,0
24 … 250 V AC + 10 %, 1.5 A, cos ϕ = 0.6
at 24 V AC min. 150 mA

Switching differential: 5 K (± 1 K)

Infinite voltage in the metal tension clamp
(included in the scope of delivery)

IP65
$142.10
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt100 150mm Q

2Z01-4111-0100-031
–35...+180 °C
PT100
Immersion length: 150 mm
4-wire connection
Output variant: M12 plug connector
IP65
$143.04
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt1000 150mm Q

2Z05-4111-0100-031
–35...+180 °C
PT1000
Insertion length: 150 mm
Two-wire connection
Output variant: M12 plug connector
IP65
$143.04
°C
Contact temperature sensor / pipe contact transmitter

THERMASGARD® ALTM2-A

1101-112E-0219-920
- 20...+ 150 °C / - 50... + 50 °C / - 20... + 80 °C / - 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

typically ± 0.2 K at +25 °C

AOS - automatic 0 -10 V/ 4...20 mA

Cable gland

IP65
$143.86
°C
Contact temperature sensor / pipe contact transmitter

THERMASGARD® ALTM2-I

1101-1122-0219-920
- 20...+ 150 °C / - 50... + 50 °C / - 20... + 80 °C / - 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typically ± 0.2 K at +25 °C
4..20mA
Cable gland
IP65
$143.86
°C
Contact temperature sensor / pipe contact transmitter

THERMASGARD® ALTM2-U

1101-1121-0219-920
- 20...+ 150 °C / - 50... + 50 °C / - 20... + 80 °C / - 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typically ± 0.2 K at +25 °C
0-10V
Cable gland
IP65
$143.86
°C
Room temperature transmitter

THERMASGARD® RTF Pt1000 PU

1101-40A0-5004-050
−30...+70 °C
Pt1000
Two-wire connection
Potentiometer (0 - 10 V) - Pressure: Marking points +3K/-3K
IP30
$143.86
°C
Room temperature transmitter

THERMASGARD® RTF Pt1000 PU

1101-40A0-5004-345
–30...+70 °C
Pt1000
2-wire connection
Potentiometer (0 - 10 V) - Pressure: Center position, unfilled
IP30
$143.86
°C
Room temperature transmitter

THERMASGARD® RTF Pt1000 PU

1101-40A0-5004-642
–30...+70 °C
Pt1000
2-wire connection
Potentiometer (0 - 10 V) - Pressure: wedge-shaped unfilled
IP30
$143.86
Connection cables for EtherCATP, 4-pin, shielded

Connection cables VLG ECATP 5.0m

2000-9131-0000-071
Connection cable
M8, EtherCAT P-coding
4-pin, shielded, with two cable connectors
Cable length: 5 m
Cable material: PUR
$144.20
°C
Room temperature sensor with operating elements in the surface switch range

THERMASGARD® FSTF LM235Z P 2L 2T

1101-5022-1672-256
passive
–30...+60 °C
2-wire connection
Potentiometer, LED displays, presence pushbutton
$144.54
% RH
Condensation monitor

HYGRASREG® KW-W

1202-1025-0001-020
Switch point: approx. 93 % RH
Relative humidity [% RH]
Changeover contact
IP 65
$145.01
°C
Room temperature sensor with operating elements in the surface switch range

THERMASGARD® FSTF NiTK P D4

1101-5021-0007-354
passive
-30...+60 °C
2-wire connection
potentiometer, rotary switch
$145.45
°C + % RH

Room operating unit with 2-point control

Rymaskon 512-MOD-RH

RYM5-10TM-2102-000

$384.04

$145.48
