°C
Room temperature sensor with operating elements in the surface switch range

THERMASGARD® FSTF Pt1000 P 2L 2T

1101-5020-5672-256
passive
−30...+60 °C
2-wire connection
Potentiometer, LED displays, presence pushbuttons
$145.83
°C
Duct temperature controller

THERMASREG® KTR-060R85

1102-3010-7205-250
Temperature controller (external setting) + safety temperature limiter
1. Temperature range: 0...+60 °C
2. Temperature range: +65...+85 °C
Tmin ± 5 K; Tmax ± 3 K
Output: switching / changeover
Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA
Operating medium: air
Protective sleeve:
made of metal, material CuZn37 (2.0321),
Ø 14 mm, NL = 205 mm
Installation lengths: approx. 205 mm (with flange);
approx. 184 mm (without flange)
IP65
$146.09
°C
Duct temperature controller

THERMASREG® KTR-090R110

1102-3010-7205-350
Temperature controller (external setpoint) + safety temperature limiter
1. Temperature range: 0...+90 °C
2. Temperature range: +90...+110 °C
Tmin ± 5 K; Tmax ± 3 K
Output: switching / changeover
Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA
Operating medium: air
Protective pocket:
made of metal, material CuZn37 (2.0321),
Ø 14 mm, NL = 205 mm
Installation lengths: approx. 205 mm (with flange);
approx. 184 mm (without flange)
IP65
$146.09
°C
Duct temperature controller

THERMASREG® KTR-090090 U

1102-3010-2205-150
Dual temperature controller (indoor setting)
1. Temperature range: 0 ... +90 °C
2. Temperature range: 0 ... +90 °C
Tmin ± 5 K; Tmax ± 3 K
Output: switching / changeover
Switching power (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA
Operating medium: air
Protective pocket:
metal, material CuZn37 (2.0321),
Ø 14 mm, NL = 205 mm
Installation length: approx. 205 mm (with flange);
approx. 184 mm (without flange)
IP65
$146.09
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt100 200mm Q

2Z01-4111-0100-041
–35...+180 °C
PT100
Insertion length: 200 mm
4-wire connection
Output version: M12 plug connector
IP65
$146.43
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt1000 200mm Q

2Z05-4111-0100-041
–35...+180 °C
PT1000
Insertion length: 200mm
2-wire connection
Output variant: M12 plug connector
IP65
$146.43
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt100 250mm Q

2Z01-4111-0100-051
−35...+180 °C
PT100
Insertion length: 250 mm
4-wire connection
Output variant: M12 plug connector
IP65
$146.87
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt1000 250mm Q

2Z05-4111-0100-051
−35...+180 °C
PT1000
Installation length: 250 mm
2-wire connection
Output version: M12 plug connector
IP65
$146.87
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt100 300mm Q

2Z01-4111-0100-061
−35...+180 °C
PT100
Installation length: 300 mm
4-wire connection
Output variant: M12 plug connector
IP65
$147.18
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt1000 300mm Q

2Z05-4111-0100-061
–35...+180 °C
PT1000
Immersion length: 300mm
Two-wire connection
Output version: M12 plug connector
IP65
$147.18
°C + % RH
Room humidity and temperature sensor

HYGRASGARD® RFTF-SD-I

1201-41D2-1000-000
0...100 % RH
0...+50 °C

typically ±2 % (20...80 % RH) at +25 °C, otherwise ±3.0 %

Temperature [°C], relative humidity [% RH]

4..20mA

IP30
$147.34
°C + % RH
Room humidity and temperature sensor

HYGRASGARD® RFTF-SD-U

1201-41D1-1000-000
0...100 % RH
0...+50 °C

typically ± 2 % (20...80 % RH) at +25 °C, otherwise ± 3.0 %

Temperature [°C], relative humidity [% RH]

0-10V

IP30
$147.34
°C
Room temperature transmitter

THERMASGARD® RTM1-Modbus

1101-42A6-0000-000
0...+50 °C

Temperature [°C], Dew point [°C]

Switchable metric / imperial

Modbus RTU

IP30
$147.96
% RH
Condensation monitor

HYGRASREG® KW-W-SD external

1202-1075-0001-040
Switch point: approx. 93 % RH
Relative humidity [% RH]
Changeover contact
IP 54
$148.49
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt100 400mm Q

2Z01-4111-0100-081
—35...+180 °C
PT100
Insertion length: 400 mm
4-wire connection
Output variant: M12 plug connector
IP65
$148.50
°C
Immersion temperature sensor

THERMASGARD® TF54 Pt1000 400mm Q

2Z05-4111-0100-081
–35...+180 °C
PT1000
Insertion length: 400 mm
Two-wire connection
Output variant: M12 plug connector
IP65
$148.50
