Humidity sensor
Our HYGRASGARD® humidity sensors for indoor and outdoor use measure the relative humidity and temperature of the ambient air. The sensor device calculates various values from these measured variables: relative humidity [% r.H.], absolute humidity [g/m³], mixing ratio [g/kg], dew point temperature [°C], enthalpy [kJ/kg] and room temperature [°C].

-
HYGRASREG® KFTF-45-U/W LCD
1201-816A-1200-000
- 0...100 % RH
- 0...+50 / -20...+50 / -20...+80 / 0...+100 °C / +32...+212 °F
- Temperature [°C], relative humidity [% RH], absolute humidity [g / m3],
Dew point [°C], mixing ratio [g / kg], wet bulb temperature [°C] - Up to three parameters in the display
- 3 active outputs (0 - 10 V or 4...20 mA)
1 changeover contact (potential-free, 48 V, 0.1 A,
switching hysteresis: 2 % of the selected scaling) - IP 65 (according to EN 60 529)
>> Housing AND sensors <<
$525.45
$625.20
-
HYGRASREG® KFTF-45-I/W LCD
1201-816B-1200-000
- 0...100 % RH
- 0...+50 / -20...+50 / -20...+80 / 0...+100 °C / +32...+212 °F
- Temperature [°C], relative humidity [% RH], absolute humidity [g / m3],
Dew point [°C], mixing ratio [g / kg], wet bulb temperature [°C] - Up to three parameters in the display
- 3 active outputs (0 - 10 V or 4...20 mA)
1 changeover contact (potential-free, 48 V, 0.1 A,
switching hysteresis: 2 % of the selected scaling) - IP 65 (according to EN 60 529)
>> Housing AND sensors <<
$525.45
$625.20
-
HYGRASREG® AFTF-45-U/W LCD
1201-716A-1200-000
- 0...100 % RH
- 0...+50 / -20...+50 / -20...+80 / 0...+100 °C
- Temperature [°C], relative humidity [% RH], absolute humidity [g / m3],
Dew point [°C], mixing ratio [g / kg], wet bulb temperature [°C] - Up to three parameters on the display
- 3 active outputs (0 - 10 V or 4...20 mA)
1 changeover contact (potential-free, 48 V, 0.1 A,
Switching hysteresis: 2 % of the selected scaling) - IP 65 (according to EN 60 529)
>> Housing AND sensors <<
$525.45
$625.20
-
HYGRASREG® AFTF-45-I/W LCD
1201-716B-1200-000
- 0...100 % RH
- 0...+50 / -20...+50 / -20...+80 / 0...+100 °C
- Temperature [°C], relative humidity [% RH], absolute humidity [g / m3],
Dew point [°C], mixing ratio [g / kg], wet bulb temperature [°C] - Up to three parameters on the display
- 3 active outputs (0 - 10 V or 4...20 mA)
1 changeover contact (potential-free, 48 V, 0.1 A,
Switching hysteresis: 2 % of the selected scaling) - IP 65 (according to EN 60 529)
>> Housing AND sensors <<
$525.45
$625.20
-
HYGRASGARD® KFTF-ECATP LCD
2003-4222-9100-001
- 0...100 % RH
-35...+80 °C - Accuracy humidity: ± 2 % / temp.: ± 0.4 K
- Temperature [°C], relative humidity [% RH],
dew point [°C], absolute humidity [g / m3],
Mixing ratio [g / kg], enthalpy [kJ / kg] - EtherCAT P
- IP 54
$526.96
$626.90
- 0...100 % RH
-
HYGRASGARD® RPFTF-25-I
1201-7122-1000-100
- 0...100 % RH
-35...+35°C
-35...+75°C
0...+50°C
0...+80°C - Accuracy humidity: ± 1.8 % / temp.: ± 0.2 K
- 4..20mA
- IP65
$527.00
$627.13
- 0...100 % RH
-
HYGRASGARD® RPFTF-25-U
1201-7121-1000-100
- 0...100 % RH
-35...+35°C
-35...+75°C
0...+50°C
0...+80°C - Accuracy humidity: ± 1.8 % / temp.: ± 0.2 K
- 0-10V
- IP65
$527.00
$627.13
- 0...100 % RH
-
HYGRASGARD® RPFTF-20-Modbus-T3 LCD
1201-6246-1400-001
- 0...100 % RH (humidity)
-35...+80 °C (temperature) - Accuracy humidity: ± 1.8 % / temp.: ± 0.2 K
- Temperature [°C], relative humidity [% RH],
dew point [°C], absolute humidity [g / m3],
Mixing ratio [g / kg], enthalpy [kJ / kg] - Modbus
- IP65
$533.89
$635.16
- 0...100 % RH (humidity)
-
HYGRASGARD® KFTF-20-wModbus LCD
1201-32CF-1400-030
- 0...100 % RH
-35...+80 °C - Accuracy humidity: ± 1.8 % / temp.: ± 0.2 K
- Temperature [°C], relative humidity [% RH],
dew point [°C], absolute humidity [g / m3],
Mixing ratio [g / kg], enthalpy [kJ / kg] - Duct sensor
- W-Modbus
- IP 65
$545.58
$649.13
- 0...100 % RH
-
-
HYGRASGARD® VFTF-I
1201-6122-1000-100
- 0...100 % RH
-35...+35 / -35...+75 / 0...+50 / 0...+80 °C - Accuracy: ± 2 %
- Relative humidity [% RH], temperature
- 4..20mA
- IP65
$564.73
$671.89
- 0...100 % RH
-
HYGRASGARD® VFTF-U
1201-6121-1000-100
- 0...100 % RH
-35...+35 / -35...+75 / 0...+50 / 0...+80 °C - Accuracy Humidity: ± 2 % / Temp.: ± 0.2 K
- Relative humidity [% RH], temperature
- 0-10V
- IP65
$564.73
$671.89
- 0...100 % RH
-
HYGRASGARD® RPFTF-20-wModbus LCD
1201-624F-1400-001
- 0...100 % RH (humidity)
-35...+80 °C (temperature) - Accuracy humidity: ± 1.8 % / temp.: ± 0.2 K
- Temperature [°C], relative humidity [% RH],
dew point [°C], absolute humidity [g / m3],
Mixing ratio [g / kg], enthalpy [kJ / kg] - W-Modbus
- IP65
$580.90
$691.10
- 0...100 % RH (humidity)
We also manufacture individually
Do you have special requirements?As a manufacturer with our own production facilities in Germany, we are always in a position to produce products outside the standard range.
