Temperature

Our quality products in the area of temperature measurement technology Thermasgard® and Thermasreg® meet the highest demands after precision, innovation and durability. S+S control technology also inspires with sophisticated thermostats, active temperature sensors and passive temperature sensors and many other solutions around the temperature measurement technology.

Your advantage: our holistic understanding of temperature measurement for a wide variety of applications and a high degree of technical experience as a manufacturer of robust and high -quality temperature sensors. If you have any questions about our product range, we are always happy to be there for you.

1281 products

°C
THERMASGARD® FSTF NTC20K D2 L

1101-5021-6631-351
Passive
-30...+60 °C
2-wire connection
LED displays, rotary switch
$92.47

$109.95
°C
THERMASGARD® FSTF NTC10K (B=3695K) D2 L

1101-5021-9631-351
Passive
-30...+60 °C
2-wire connection
LED displays, rotary switch
$92.47

$109.95
°C
THERMASGARD® FSTF KTY81-210 D2 L

1101-5022-0631-351
Passive
-30...+60 °C
2-wire connection
LED displays, rotary switch
$92.47

$109.95
°C
THERMASGARD® ASTF KTY81-210

1101-1062-0001-000
Passive

-30...+75 °C

2-wire connection
$92.50

$109.98
°C
THERMASGARD® FSTF Pt100 D2 L

1101-5020-1631-351
Passive
-30...+60 °C
2-wire connection
LED displays, rotary switch
$92.60

$110.08
°C
THERMASGARD® FSTF Pt1000 D2 L

1101-5020-5631-351
Passive
-30...+60 °C
2-wire connection
LED displays, rotary switch
$92.60

$110.08
°C
THERMASREG® KTR-1

1102-3010-1100-150
Temperature controller (external setting)

-35 ... +35 °C

Tmin ± 5 K; Tmax ± 3 K

Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA

Switching differential: 3 K

Installation length:
approx. 205 mm (with flange);
approx. 184 mm (without flange)

Protection tube:
made of metal, material CuZn37 (2.0321),
Ø 14 mm, NL = 205 mm

IP65
$92.60

$110.08
°C
THERMASREG® KTR-060

1102-3010-1100-350
Temperature controller (external setting)

0 ... +60 °C

Tmin ± 5 K; Tmax ± 3 K

Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA

Switching differential: 3 K

Installation length:
approx. 205 mm (with flange);
approx. 184 mm (without flange)

Protection tube:
made of metal, material CuZn37 (2.0321),
Ø 14 mm, NL = 205 mm

IP65
$92.60

$110.08
°C
THERMASREG® KTR-090

1102-3010-1100-450
Temperature controller (external setting)

0 ... +90 °C

Tmin ± 5 K; Tmax ± 3 K

Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA

Switching differential: 3 K

Installation length:
approx. 205 mm (with flange);
approx. 184 mm (without flange)

Protection tube:
made of metal, material CuZn37 (2.0321),
Ø 14 mm, NL = 205 mm

IP65
$92.60

$110.08
°C
THERMASREG® KTR-0120

1102-3010-1100-550
Temperature controller (external setting)

0 ... +120 °C

Tmin ± 5 K; Tmax ± 3 K

Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA

Switching differential: 5 K

Installation length:
approx. 205 mm (with flange);
approx. 184 mm (without flange)

Protection tube:
made of metal, material CuZn37 (2.0321),
Ø 14 mm, NL = 205 mm

IP65
$92.60

$110.08
°C
THERMASREG® KTR-50140

1102-3010-1100-650
Temperature controller (external setting)

+50 ... +140 °C

Tmin ± 5 K; Tmax ± 3 K

Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA

Switching differential: 5 K

Installation length:
approx. 205 mm (with flange);
approx. 184 mm (without flange)

Protection tube:
made of metal, material CuZn37 (2.0321),
Ø 14 mm, NL = 205 mm

IP65
$92.60

$110.08
°C
THERMASREG® KTR-060 U

1102-3010-2100-350
Temperature monitor (internal setting)

0 ... +60 °C

Tmin ± 5 K; Tmax ± 3 K

Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA

Switching differential: 3K

Installation length:
approx. 205 mm (with flange);
approx. 184 mm (without flange)

Protection tube:
made of metal, material CuZn37 (2.0321),
Ø 14 mm, NL = 205 mm

IP65
$92.60

$110.08
°C
THERMASREG® KTR-090 U

1102-3010-2100-450
Temperature monitor (internal setting)

0 ... +90 °C

Tmin ± 5 K; Tmax ± 3 K

Switching capacity (contact load):
24...250 V AC +10 %, 10 A, cos ϕ = 1.0
24...250 V AC +10 %, 1.5 A, cos ϕ = 0.6
at 24 V at least 150 mA

Switching differential: 3K

Installation length:
approx. 205 mm (with flange);
approx. 184 mm (without flange)

Protection tube:
made of metal, material CuZn37 (2.0321),
Ø 14 mm, NL = 205 mm

IP65
$92.60

$110.08
°C
THERMASGARD® RTM1-A

1101-41AE-0000-200
- 20...+ 150 °C / - 50... + 50 °C / - 20... + 80 °C / - 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typically ± 0.2 K at +25 °C
AOS - automatic 0 -10 V/ 4...20 mA
IP30
$92.72

$110.20
°C
THERMASGARD® RTM1-I

1101-41A2-0000-200
- 20...+ 150 °C / - 50... + 50 °C / - 20... + 80 °C / - 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typically ± 0.2 K at +25 °C
4..20mA
IP30
$92.72

$110.20
°C
THERMASGARD® RTM1-U

1101-41A1-0000-200
- 20...+ 150 °C / - 50... + 50 °C / - 20... + 80 °C / - 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C
typically ± 0.2 K at +25 °C
0-10V
IP30
$92.72

$110.20
