Temperature

Our quality products in the area of temperature measurement technology Thermasgard® and Thermasreg® meet the highest demands after precision, innovation and durability. S+S control technology also inspires with sophisticated thermostats, active temperature sensors and passive temperature sensors and many other solutions around the temperature measurement technology.

Your advantage: our holistic understanding of temperature measurement for a wide variety of applications and a high degree of technical experience as a manufacturer of robust and high -quality temperature sensors. If you have any questions about our product range, we are always happy to be there for you.

°C
THERMASGARD® FSTF LM235Z D2 L

1101-5022-1631-351
Passive
-30...+60 °C / -22...-140 °F
2-wire connection
LED displays, rotary switch
$96.03

incl. VAT $114.27
°C
THERMASGARD® TM43-I 300mm

1101-7112-0069-900
Installation length: 300mm / 12 in

- 20...+ 150 °C / - 50... + 50 °C / - 20... + 80 °C / - 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

4...20 mA

IP54
$96.50

incl. VAT $114.74
°C
THERMASGARD® TM43-U 300mm

1101-7111-0069-900
Installation length: 300mm / 12 in

- 20...+ 150 °C / - 50... + 50 °C / - 20... + 80 °C / - 30... + 60 °C / 0... + 40 °C / 0... + 50 °C (default) / 0...+ 100 °C / 0...+ 150 °C

0 - 10 V

IP54
$96.50

incl. VAT $114.74
°C
THERMASREG® ETR-0120 MS/200

1102-2010-1100-520
Temperature controller (external setting)
0 ... +120 °C
Tmin ± 5 K; Tmax ± 3 K
Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
Switching differential: 5K
Installation length: 200 mm / 8 in
Brass
IP65
$96.50

incl. VAT $114.74
°C
THERMASREG® ETR-060 MS/200

1102-2010-1100-320
Temperature controller (external setting)
0 ... +60 °C
Tmin ± 5 K; Tmax ± 3 K
Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
Switching differential: 3K
Installation length: 200 mm / 8 in
Brass
IP65
$96.50

incl. VAT $114.74
°C
THERMASREG® ETR-090 MS/200

1102-2010-1100-420
Temperature controller (external setting)
0 ... +90 °C
Tmin ± 5 K; Tmax ± 3 K
Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
Switching differential: 3K
Installation length: 200 mm / 8 in
Brass
IP65
$96.50

incl. VAT $114.74
°C
THERMASREG® ETR-1 MS/200

1102-2010-1100-120
Temperature controller (external setting)
-35 ... +35 °C
Tmin ± 5 K; Tmax ± 3 K
Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
Switching differential: 3K
Installation length: 200 mm / 8 in
Brass
IP65
$96.50

incl. VAT $114.74
°C
THERMASREG® ETR-50140 MS/200

1102-2010-1100-620
Temperature controller (external setting)
+50 ... +140 °C
Tmin ± 5 K; Tmax ± 3 K
Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
Switching differential: 5K
Installation length: 200 mm / 8 in
Brass
IP65
$96.50

incl. VAT $114.74
°C
THERMASREG® ETR-060 U MS/200

1102-2010-2100-320
Temperature monitor (internal setting)
0 ... +60 °C
Tmin ± 5 K; Tmax ± 3 K
Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
Switching differential: 3K
Installation length: 200 mm / 8 in
Brass
IP65
$96.50

incl. VAT $114.74
°C
THERMASREG® ETR-090 U MS/200

1102-2010-2100-420
Temperature monitor (internal setting)
0 ... +90 °C
Tmin ± 5 K; Tmax ± 3 K
Switching capacity (contact load): 24...250 V AC +10 %, 10 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
Switching differential: 3K
Installation length: 200 mm / 8 in
Brass
IP65
$96.50

incl. VAT $114.74
°C
THERMASGARD® TF54 Pt100 100mm KV

1101-7070-1023-000
-35...+180 °C / -31...-356 °F
PT100
Installation length: 100mm / 4 in
4-wire connection
Output variant: Cable gland
IP65
$96.51

incl. VAT $114.75
°C
THERMASGARD® TF54 Pt1000 100mm KV

1101-7070-5021-000
-35...+180 °C / -31...-356 °F
PT1000
Installation length: 100mm / 4 in
2-wire connection
Output variant: Cable gland
IP65
$96.51

incl. VAT $114.75
°C
THERMASREG® TR-22 U

1102-1050-2100-100
Temperature monitor (automatic switching)
-35... +35°C
Tolerance: Tmin ± 3 K; Tmax ± 3 K
Switching capacity (contact load):24...250 V AC +10 %, 16 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
Capillary: Copper
IP65
$96.59

incl. VAT $114.83
°C
THERMASREG® TR-040 U

1102-1050-2100-200
Temperature monitor (automatic switching)
0... +40°C
Tolerance: Tmin ± 3 K; Tmax ± 3 K; at +20 °C ± 1K
Switching capacity (contact load):24...250 V AC +10 %, 16 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
Capillary: Stainless steel, 1.4303, V2A
IP65
$96.59

incl. VAT $114.83
°C
THERMASREG® TR-060 U

1102-1050-2100-300
Temperature monitor (automatic switching)
0... +60°C
Tolerance: Tmin ± 3 K; Tmax ± 3 K; at +20 °C ± 1K
Switching capacity (contact load):24...250 V AC +10 %, 16 A, cos ϕ = 1.024...250 V AC +10 %, 1.5 A, cos ϕ = 0.6at 24 V at least 150 mA
Capillary: Stainless steel, 1.4303, V2A
IP65
$96.59

incl. VAT $114.83
°C
THERMASGARD® TF54 Pt100 200mm KV

1101-7070-1043-000
-35...+180 °C / -31...-356 °F
PT100
Installation length: 200mm / 8 in
4-wire connection
Output variant: Cable gland
IP65
$97.61

incl. VAT $116.04

We also manufacture individually

Do you have special requirements? As a manufacturer with our own production facilities in Germany, we are also able to produce products outside of the standard range at any time.
